Wear Resistant Steel Plate
Wear Resistant Steel Plate - Image 2
Wear Resistant Steel Plate - Image 3

Wear Resistant Steel Plate

Our range of wear-resistant steel plates (NM400, NM450, NM500, NM600 / AR400, AR450, AR500, AR600) are carefully produced by high-quality wear-resistant steel manufacturers with guaranteed quality and are widely used in heavy-duty machinery, mining equipment, and construction machinery industries. As a reliable wear-resistant steel supplier, we can provide you with competitive prices and stable inventory to ensure timely delivery.

Category:

Description

Product Details

Product Name

Wear-Resistant Steel Plate
Specification Thickness:3mm-200mm,Width:1500-2000mm,Length:6000mm-12000mm
Customized sizes are accepted
Standard RXEX and NM STEEL PLATS
Grade DIN: XAR300,XAR400, XAR450, XAR500, XAR600, DILLIDUR400V,DILLIDUR450V,DILLIDUR500V; X120Mn12; 1.3401; SSABWELDOX700,WELDOX900,WELDOX960; NF: FORA400,FORA500,Creusabro4800,Creusabro8000;

EN: QUARD400,QUARD450,QUARD500 ; RAEX320,RAEX400,RAEX450,RAEX500;

DUrostat400,DUrostat450,DUrostat500;  JIS: JFE-EH360,JFE-EH400,JFE-EH500, WEL-HARD400, WEL-HARD500;

SUMIHARD-K340,SUMIHARD-K400,SUMIHARD-K500 GB: NM360,NM400,M450,NM500,NM550,

NM600,NR360,NR400,B-HARD360,B-HARD400,B-HARD450,KN-55,KN-60,KN-63.
Surface treatment

Coated, Galvanized
Technical treatment Tempering and hardening
Brand name XINYU, WU STEEL, BAOSTEEL, AND OTHER TOP STEEL MILLS
Application Boiler plate, Container plate, Flange plate, Ship plate
Delivery time Within 7-15 workdays

Chemical composition and mechanical properties

Material C Si Mn P S Cr Mo Cu Ni B
XAR400 0.20 0.80 1.50 0.025 0.010 1.00 0.50 — — 0.005
XAR450 0.22 0.80 1.50 0.025 0.012 1.30 0.50 0.30 — 0.005
XAR500 0.28 0.80 1.50 0.025 0.010 1.00 0.50 — — 0.005
XAR600 0.40 0.80 1.50 0.025 0.010 1.50 0.50 — 1.50 0.005
Material Yield StrengthReh MPa Tensile Strength Rm MPa Elongation BH(Brinell Hardness)
XAR400 1150 1300 ≥12 360-440
XAR450 1200 1350 ≥10 410-490
XAR500 1500 1600 ≥9 450-530
XAR600 — — — ≥550
